Product Description

🚀 Wi‑Fi Standards & Performance

• 802.11ac Wave 2 with 4×4 MU‑MIMO (3 spatial streams), delivering up to 5.2 Gbps aggregated throughput (2×2.6 Gbps over dual 5 GHz radios) r

• Supports 80/160 MHz channels, Dynamic Bandwidth Selection, and beamforming for optimal data rates

• High-density RF: Cisco CleanAir, ClientLink 4.0, cross-AP noise coordination, turbo performance—ideal for crowded environments

📡 Radio & Antenna Design

• 3802i: Dual internal radios (2.4 GHz + 5 GHz), omnidirectional

• 3802e/3802p: External antenna ports + smart-antenna connector for flexible deployment modes—plug in a second antenna or use as a security/monitoring radio

🔌 Networking & Power

• Dual Multigigabit Ethernet ports: 2.5 GbE/5 GbE uplink + 1 GbE auxiliary · supports link aggregation (LAG)

• PoE+ (802.3at) or Cisco UPOE required—full performance kicks in only with adequate power; standard PoE (15 W) may limit functionality

🧠 Best Use Cases

• Ideal for high-density indoor environments such as auditoriums, open-plan offices, classrooms, and event spaces.

• Excellent when you need dual 5 GHz radios, strong roaming support, and RF monitoring on-the-fly.

• If deploying in remote or power-constrained sites, ensure PoE+ availability; otherwise performance will degrade.
